Zinc-aluminum-magnesium coated steel coil
Another name:
Zn-Al-Mg alloy coated steel coil, ZAM coated steel coil, Zinc-aluminum-magnesium alloy coated steel coil
Zinc-aluminum-magnesium coated steel coil is a new type of high corrosion-resistant coating product. it is also called Zn-Al-Mg alloy coated or ZAM coated steel coil. The coating consisting of over 85% zinc, 11% aluminum, 3% magnesium and trace silicon etc, It have far superior corrosion resistance to traditional zinc and aluzinc coatings. It can be used instead of stainless steel or aluminum in some fields. The excellent anti-corrosion and self-healing effect in the cutting surface is the major feature of the product. It is widely used in civil construction such as keel ceilings, perforated plates, steel structure, steel structure accessories and cable trays etc.; railway roads; high and low voltage switchgear for power transmission and distribution, Box-type substation outer body etc.; automotive motors; industrial refrigeration such as cooling towers, large outdoor industrial air conditioners etc. and other industries.
Specifications
Standards | ASTM/AISI/BS/DIN/JIS/GB etc. |
Certificates | ISO9001/ISO14001/SGS/PVOC/SONCAP |
Base metal | CRC/HRC |
Thickness | 0.25-2.5mm |
Width | 600-1250mm |
ZAM Coating | 20-350g/m² |
Hardness | HRB55-HRB95 |
Guard film | PVC etc. |
Surface treatment | Chromated/skin-pass/oiled/slight-oiled/dry |
Production Line
The annual capacity of Galvanized steel 120,000 tons.
Prepainted color coated coil Production Process Flow Chart
Quality Control
We have advanced testing center Lab. and team to control our product quality.
Packing Details
1) 4 eye steel bands and 4 circumferential steel bands.
2) Galvanized steel fluted rings on inner and outer edges.
3) Galvanized steel sheet and waterproof paper wall protection.
4) Galvanized steel and waterproof paper around circumference and bore protection.
